Neumann KM-143 Wide Cardioid Microphone with SG 21 BK - WNS 100 - Woodbox

Neumann KM-143 Wide Cardioid Woodbox Microphone - Your Ultimate Recording Companion

Unleash your creativity with the Neumann KM-143 Wide Cardioid Microphone! This remarkable microphone is a game-changer for live sound reinforcement and broadcast. Here's why:

• • Versatile Capsules: Choose from seven active capsules with different directional characteristics, including omnidirectional, cardioid, and wide-angle cardioid. The modular construction allows for easy adaptation to various applications.
• • Invisible Performance: The microphone is nearly undetectable during use with cameras, on stage, or suspended from the ceiling in a concert hall. Its compact size makes it a perfect choice for any situation.
• • High-Quality Sound: With a frequency range of 20 Hz to 20 kHz, a maximum SPL of 135 dB SPL, and low noise levels, the KM-143 delivers exceptional sound quality for professional recordings.

Technical Specifications:

• • Microphone:
  • Operating Principle: Pressure Gradient
  • Capsule: Condenser
  • Polar Pattern: Omnidirectional
• • Performance:
  • Frequency Range: 20 Hz to 20 kHz
  • Maximum SPL: 135 dB SPL
  • Impedance: 50 Ohms
  • Load Impedance: 1000 Ohms
  • Sensitivity: 12 mV/Pa at 1 kHz into 1 Kilohms
  • Signal-to-Noise Ratio:
    • 69 dB CCIR
    • 81 dB A-Weighted
  • Equivalent Noise Level:
    • 25 dB CCIR
    • 13 dB A-Weighted
  • THD: 0.50%
• • Connectivity:
  • Output Connectors (Analog): 1 x XLR 3-Pin
• • Power:
  • Operating Voltage: 48 V ± 4 V
  • Operating Current Consumption: 3.2 mA
• • Physical:
  • Dimensions: 0.87 x 4.21' / 22 x 107 mm
  • Weight: 2.82 oz / 80 g
• • Packaging Info:
  • Package Weight: 0.6 lb
  • Box Dimensions (LxWxH): 9.8 x 3.1 x 2.3'

The Neumann KM-143 Wide Cardioid Microphone is perfect for live sound reinforcement and broadcast. It's small and lightweight, measuring 0.87 x 4.21' / 22 x 107 mm and weighing 2.82 oz / 80 g. Choose from seven active capsules with different directional characteristics for versatile use. The microphone is nearly invisible during use with cameras, on stage, or suspended from the ceiling in a concert hall.
