Neutrik NLT4MXX 4-Pole Metal Housing Male Cable Connector - Your Reliable Connectivity Solution
Get the Neutirk NLT4MXX 4 pole male cable connector with a metal housing and chuck type strain relief. This connector is fully compliant with the device standard IEC 62368-1, thanks to its component certification according to IEC 61984. The speakON STXX Series is specially designed for heavy-duty amplifier-loudspeaker applications like professional touring. The extremely rugged and durable STXX Series features an all-metal housing.
Features:
- • IEC 61984 certified, IEC 62368-1 compliant - Ensures top-notch safety and performance.
- • Extremely robust metal housing and glass reinforced V-0 material insert - Built to withstand tough conditions.
- • Uses precise 'Quick Lock' system - Makes connection a breeze.
Specifications:
- Gender: male
- Contact resistance: < 2 mΩ
- Dielectric strength: 2.8 kVac
- Insulation resistance: >0.1 GΩ (after dampheat)
- Rated current per contact: 30 A rms continuous
- Rated voltage: 250 V ac
- Attention: speakON is NOT to be used as an AC mains or power supply connector!
- Cable O.D.: 9 - 16 mm
- Lifetime: > 5000 mating cycles
- Wiresize: 6 mm2
- Wiresize: 10 AWG
- Termination: Solder contacts
- Locking device: Quick Lock
- Contact plating: Ag
- Contacts: Copper Alloy
- Shell: Zinc diecast, Ni plated
- Insert: Polyamide (PA 66)
- Strain relief: Polyacetal (POM)
- Temperature range: -30 °C to +80 °C
- Flammability: UL 94 V-0
- Protection class: IP 54 (mated condition)
- Solderability: Complies with IEC68-2-20
This Neutrik NLT4MXX 4-Pole Male Cable Connector with Metal Housing is perfect for professional touring setups, especially for connecting amplifiers to loudspeakers. It's designed for audio professionals who demand reliable connectivity. The connector has a metal housing for durability. Cable O.D. ranges from 9 - 16 mm. It offers high performance with features like a 'Quick Lock' system and is rated for 30 A rms continuous current per contact, 250 V ac rated voltage, and has a lifetime of over 5000 mating cycles.
