Panasonic 4K POV Camera - Your Ultimate Shooting Companion
Unleash your creativity with this compact and lightweight camera! Inheriting the features of the first-generation POVCAM and adding the ease of touch panel operation, it's perfect for free-style shooting. Network operation via LAN enables IP control and streaming, allowing you to zoom and monitor in real-time with a PC or tablet. Double SDXC memory card slots offer extended recording capabilities. The newly designed 4K camera head features a high-resolution progressive MOS sensor and a 29.5mm wide-angle optical 20x zoom lens for stunning visuals.
Features:
- Free-Style Shooting
- Compact camera head for flexible installation
- Lightweight and battery-driven recorder
- Touch-panel LCD monitor
- IP Network Operation
- LAN terminal for IP streaming and control
- REMOTE terminal for focus and iris control
- Simultaneous 3G-SDI and HDMI outputs
- Versatile interfaces
- Memory Card Slots
- AVCHD acquisition in high-quality modes
- Double SDXC memory card slots
- Professional recording functions
- Convenient playback for presentations
- 4K Camera Head
- High-resolution progressive MOS sensor
- 29.5mm wide-angle optical 20x zoom lens
- Five-axis hybrid image stabilizer for smooth shots
- Advanced picture adjustments
- Versatile camera functions
Specifications:
- General
- Power: DC 9V (from AG-UMR20)
- Power consumption: 0.6A
- Operating temperature: 0°C - 40°C (32°F - 104°F)
- Operating humidity: 10% - 80% (no condensation)
- Weight: Approx. 325g (0.717 lbs)
- Dimensions(W x H x D): 64mm x 72mm x 131mm (excluding protrusion)(2-17/32 inches x 2-27/32 inches x 5-5/32 inches)
- Camera
- Pickup device: 1/2.3-type MOS solid state image sensor (Total pixels: approx. 12.76 megapixels)
- Lens:
- Zoom: optical 20x motorized zoom
- Fvalue: F1.8 - F3.6, Focal length: f = 4.08mm - 81.6mm
- 35mm conversion: 29.5mm - 612.0mm
- (Hybrid O.I.S mode “OFF”)
- Filter diameter : 49mm, ND filter: CLEAR, 1/4, 1/16, 1/64 (built-in)
- Shortest shooting distance: 1.5m (4.9 ft) at zoom range, 3cm (0.1 ft) at wide angle
- IR cut filter: incorporates ON/OFF control function
- Zoom:
- i. Zoom: x30 (HD), x22 (4K)
- Digital zoom: x1.4, x2, x4, x6, x8
- Image stabilizer:
- Optical image stabilizer (HD/4K)
- 5-Axis hybrid image stabilizer (HD)
- Gain setting: Automatic, manual 0 dB to 30 dB(1 dB step), Super Gain 33 dB, 36 dB *At auto mode, 3 dB to 30 dB (3 dB steps) can be selected with AGC limit setting.
- White balance: ATW, ATW LOCK, AWB A, AWB B, P3200K, P5600K, VAR (2000 K to 15000 K)
- Shutter speed: 59.94i/59.94p mode: 1/60 sec., 1/100 sec., 1/120 sec., 1/180 sec., 1/250 sec., 1/350 sec., 1/500 sec., 1/750 sec., 1/1000 sec., 1/1500 sec., 1/2000 sec., 1/3000 sec., 1/4000 sec., 1/8000 sec. 29.97p mode: 1/30 sec., 1/50 sec., 1/60 sec., 1/100 sec., 1/120 sec., 1/180 sec. to 1/8000 sec. (same as above) 23.98p mode: 1/24 sec., 1/48 sec., 1/50 sec., 1/60 sec., 1/100 sec., 1/120 sec., 1/180 sec. to 1/8000 sec. (same as above) 50i/50p mode: 1/50 sec., 1/60 sec., 1/100 sec., 1/125 sec., 1/180 sec. to 1/8000 sec. (same as above) 25.00p mode: 1/25 sec., 1/50 sec., 1/60 sec., 1/100 sec., 1/125 sec., 1/180 sec. to 1/8000 sec. (same as above)
- Slow shutter: 59.94i/59.94p mode: 1/2 sec., 1/4 sec., 1/8 sec., 1/15 sec., 1/30 sec. 29.97p mode: 1/2 sec., 1/4 sec., 1/8 sec., 1/15 sec. 23.98p mode: 1/2 sec., 1/3 sec., 1/6 sec., 1/12 sec. 50i/50p mode: 1/2 sec., 1/3 sec., 1/6 sec., 1/12 sec., 1/25 sec., 25.00p mode: 1/2 sec., 1/3 sec., 1/6 sec., 1/12 sec.
- Synchro scan: 59.94i/59.94p mode: 1/60.0 sec. to 1/285.6 sec. 29.97p mode: 1/30.0 sec. to 1/206.5 sec. 23.98p mode: 1/24.0 sec. to 1/280.1 sec. 50i/50p mode: 1/50.0 sec. to 1/209.2 sec. 25p mode: 1/25.0 sec. to 1/224.3 sec.
- Minimum illumination: 0.2 lx (slow shutter: 1/2 sec., gain: +36 dB)
- Horizontal resolution:
- 1,300 TV (HDMI output 2160/29.97p, when 25.00p playback)
- (Typ, Center) 1,000 TV (HDMI output 1080/59.94p, when 50.00p playback)
- Input/Output
- AUDIO IN: Built-in microphone (2 CH stereo)
- Connecter: 20 pin dedicated interface (to the AG-UMR20)
The Panasonic 4K POV Camera is perfect for content creators, vloggers, and professionals on the go. Its compact size (64mm x 72mm x 131mm) and lightweight design (approx. 325g) make it easy to carry around. With features like free-style shooting, IP network operation, and double SDXC memory card slots, it offers endless possibilities for capturing high-quality footage. Whether you're shooting action sports, documenting events, or creating engaging videos, this camera has got you covered.
