Shure ULXD4D Dual Digital Wireless Receiver - The Ultimate Sound Solution for Large Venues
Upgrade your sound system with the Shure ULXD4D Dual Digital Wireless Receiver! This powerful receiver is part of the ULX-D wireless series and offers a range of features that make it perfect for professional sound reinforcement applications in large live venues, houses of worship, and A/V installations in conference, educational, and corporate facilities.
Key Features:
- • Dual digital receivers in a single-rack unit for easy setup and management
- • Ethernet ports for Dante digital audio and RF cascade ports for antenna signal distribution
- • Audio summing allows the receiver to function as a 2-channel mixer
Benefits:
- • Delivers pristine 24-bit/48 kHz digital audio for crystal-clear sound
- • Compatible with a wide selection of Shure transmitters and mic capsules
- • Secure AES-256 encryption for peace of mind
Technical Specifications:
- • Wireless Technology: Digital UHF
- • Number of RF Channel Frequencies: 2560
- • Diversity: Antenna Diversity
- • RF Frequency Band (H50): 534 to 598 MHz
- • RF Bandwidth: 64 MHz
- • Frequency Step Size: 25 kHz
- • Max Operating Range: 328.1' / 100 m
- • Max Transmitters per Band: 60
- • Latency: < 2.9 ms
- • Modulation: Proprietary
- • Receiver Type: Rackmount
- • Mounting Options: Rackmount (with Included Hardware)
- • Rackmount Size: 1 RU (Full Rack)
- • Antenna: 2 x 1/2 Wave External, BNC (Rear-Mount)
- • Antenna Bias Voltage: 12 to 13 VDC, 150 mA (per Antenna)
- • Number of Audio Channels: 2
- • Audio I/O: 2 x XLR 3-Pin Male Balanced Output
- • Gain Range: -18 to +42 dB (1 dB Steps)
- • Pad: 30 dB
- • Audio Output Level: +18 dBV (Line Level, Balanced) or -12 dBV (Mic Level)
- • Phantom Power Protection: On XLR Outputs
- • Frequency Response: 30 Hz to 20 kHz ±1 dB (Dependent on Mic)
- • Network I/O: 2 x RJ45 (1 Gb/s)
- • Network Protocols: DHCP, Dante, Manual IP
- • Impedance: XLR Output: 100 Ohms (Balanced)
- • Approximate RF Sensitivity: -98 dBm
- • Adjacent Channel Isolation: >70 dB
- • Spurious: Rejection: >80 dB
- • Power Requirements: AC Input
- • AC Input Power: 100 to 240 VAC, 50 / 60 Hz at 0.32 A
- • Display & Indicators: 1 x Backlit LCD (Battery Status, Channel, Group, Menu Navigation) and 2 x Multi-Segment LED (AF Level, Output Level, Peak)
- • Housing: Steel
- • Operating Temperature: 0 to 122 °F / -17 to 50 °C
- • Storage Temperature: -20 to 165 °F / -28 to 73 °C
- • Dimensions: 19 x 1.7 x 10.8' / 482 x 44 x 274 mm
- • Weight: 7.4 lb / 3.4 kg
- • Package Weight: 11.95 lb
- • Box Dimensions (LxWxH): 27.5 x 17.5 x 3.6'
The Shure ULXD4D Dual Digital Wireless Receiver is a must-have for professionals in the sound industry. It's perfect for large live venues, houses of worship, and A/V installations in conference, educational, and corporate facilities. With its rugged single-rack unit and internal power supply, it's easy to set up and manage. The receiver features 2 independent digital receivers, 2 Ethernet ports for Dante digital audio, and RF cascade ports for antenna signal distribution. It also has audio summing, allowing it to function as a 2-channel mixer. The ULX-D Series simplifies the setup and management of large numbers of wireless systems. Compatible with a wide selection of Shure transmitters and mic capsules, it delivers pristine 24-bit/48 kHz digital audio. The receiver has a 64 MHz tuning range, is expandable up to 60 channels, and offers secure AES-256 encryption. It has a rackmount size of 1 RU (full rack), dimensions of 19 x 1.7 x 10.8' / 482 x 44 x 274 mm, and weighs 7.4 lb / 3.4 kg. The package weight is 11.95 lb, and the box dimensions are 27.5 x 17.5 x 3.6'.
