Toshiba IK-4KH Ultra-Compact 4K 3CMOS Camera Head
The Toshiba IK-4KH is a game-changer! It's the world's tiniest 3-chip Ultra HD 4K video camera. Use it solo or pair it with an ACS 4K Fibre Transmission System and RCP for live production. • Stunning 8Mp 3840x2160 output with up to 1600 TV lines of resolution for extraordinary detail. • Video output switches between 4K, 1080p, and 1080i for any HD display. • Ideal for live events, content creators, and videographers seeking top-notch quality.
Features:
- 4 x 3G/HD-SDI output for maximum signal fidelity
- 12 channel colour adjustment for exceptional colour accuracy and control
- 5 user configurable settings files for different operating modes
- Image flip & mirror/Freeze frame
- Gen lock for 3D and multi camera use
- 10m CCU Cable
- C-mount lens mount
- Comes with Fujinon TF4XA-1 4mm lens
- 4K Fibre Transmission System with RCP control for live OB/Production
- Range of mounting accessories available
Specifications:
- IMAGE SENSOR: 3-CMOS, 1/2.9”, progressive
- OUTPUT MATRIX:
- Horizontal: 3840, Vertical: 2160 UHD 4K mode
- Horizontal: 1920, Vertical: 1080 HD 1080p/1080i
- OUTPUT RESOLUTION H/V:
- 1600 TV lines standard UltraHD 4K mode
- 1000 TV lines or more 1080p/1080i modes
- SENSITIVITY:
- F5.6 standard (59.94 Hz setting)
- F6.1 standard (50 Hz setting)(at 2000 lx, 3000K)
- MINIMUM ILLUMINATION:
- 19.5 lx (59.94 Hz setting)
- 16.2 lx (50 Hz setting) at F2.2, 24dB
- S/N RATIO:
- 58 dB standard
- AGC: OFF, Gamma: OFF, Enhance: OFF,
- Colour matrix: OFF, Colour temp: 5600K
- OPERATING TEMPERATURE: 0oC to 40o C/32o F to 104o F
- OPERATING HUMIDITY: Less than 90% (non-condensing)
- WEIGHT: Approximately 70g (2.5oz)
- DIMENSIONS: W: 32.6mm H: 38.6mm D: 41mm (1.28”x1.52”x1.61”)(protruding portion not included)
- LENS: Fujinon TF4XA-1 4mm f/2.2 to 2/16 High Definition lens
- ACS FIBRE TRANSMISSION SYSTEM: Quad HD SDI and RCP (includes motorised iris control) requires 2 x single mode fibre and local power
The Toshiba IK-4KH Ultra-Compact 4K 3CMOS Camera Head is perfect for live event videographers, content creators, and anyone seeking high-quality footage. Weighing only 70g (2.5oz) and measuring W: 32.6mm H: 38.6mm D: 41mm (1.28”x1.52”x1.61”), it's highly portable. It offers 8Mp 3840x2160 output with up to 1600 TV lines of resolution, and video output is switchable between 4K, 1080p, and 1080i formats. Ideal for various HD displays and applications, it comes with features like 4 x 3G/HD-SDI output, 12 channel colour adjustment, and 5 user configurable settings files.
