L-Acoustics Syvalow Speaker Baseplate - Boost Your Bass
Get an incredible passive low-end extension! • Two high-excursion, direct-radiating 12 in transducers in a bass-reflex tuned enclosure with laminar vents for increased LF efficiency. • The enclosure cabinet is made of premium grade Baltic beech and birch plywood. • The enclosure front is protected by a coated steel grill and an acoustically transparent fabric. The enclosure has a signal connector on the top panel to connect to the companion full-range enclosure. It's exclusively driven and protected by a proprietary amplified controller through a dedicated preset.
Specifications:
- Coverage:
- Enclosure directivity: standard
- Transducers:
- LF transducer: 2 ¡Á12' cone drivers
- Acoustics:
- Nominal impedance: 4
- Usable bandwidth: 40 Hz - 130 Hz (-10 dB), 42 Hz - 110 Hz (-6 dB), 47 Hz - 93 Hz (-3 dB)
- RMS power handling (Calculated using the mean impedance measured on the usable bandwidth): 894 W
- Maximum SPL: 137 dB Peak level at 1 m under half space conditions using pink noise with crest factor 4
- Physical data:
- Acoustical load: bass-reflex
- Cabinet: premium grade Baltic beech and birch plywood
- Dimensions (W, H, D): 849 mm, 334 mm, 350 mm / 33.4 in, 13.1 in, 13.8 in
- Weight (net): 29 kg / 64 lbs.
- Connectors:
- 1 ¡Á 4-point speakON
- 1 x proprietary connector
- IP: IP55
- Finish:
- dark grey brown Pantone 426 C
- pure white RAL 9010
- custom RAL code on special order
This L-Acoustics Syvalow Speaker Baseplate is perfect for sound systems in various venues like clubs, theaters, or live events. Ideal for audio engineers, event planners, and anyone seeking top-notch bass performance. It features two 12-inch transducers for enhanced bass, a cabinet made of premium materials, and comes in multiple finish options. Dimensions are 849 mm (W) x 334 mm (H) x 350 mm (D) weighing 29 kg (net).
