Shure P10R+-H22 Diversity Bodypack Receiver for PSM 1000 - H22 Band
The P10R+ is an ultra-slim bodypack receiver for the PSM 1000 Wireless Personal Monitor System. It's a must-have for performers! Here's why:
- • Unmatched Signal Stability: Enjoy full bandwidth RF scan and Automatic RF Gain Control for a rock-solid connection.
- • Easy Mix Monitoring: CueMode lets you monitor different stage mixes and store up to 20 channels for quick reference.
- • Long-Lasting Power: Optional advanced rechargeability means no more disposable batteries and extended usage times.
With features like improved audio quality, enhanced RF performance, and updated firmware, the P10R+ is a game-changer. It also has a 4-band parametric EQ and added Power-Save Mode.
Specifications:
- Tri-band RF Filtering: –3 dB at 30.5 MHz from the center frequency of each band
- Active RF Gain Control: 31 dB (adjusts RF sensitivity to provide more RF dynamic range)
- RF Sensitivity (20 dB SINAD): 2.2 μV
- Squelch Threshold: 22 dB SINAD (±3 dB), default setting
- Adjacent Channel Rejection: >70 dB
- Intermodulation Attenuation: >70 dB
- Blocking: >80 dB
- Image Rejection: >90 dB
- Audio Output Power (1kHz @ <1% distortion, peak power, @16Ω): 100 mW per output
- Minimum Load Impedance: 4 Ω
- Output Impedance: <1 Ω
- 4-Band Parametric EQ:
- Low Shelf:
- Selectable Gain: ±2 dB, ±4 dB, ±6 dB @100 Hz
- Low Mid:
- Selectable Gain: ±2 dB, ±4 dB, ±6 dB @160 Hz, 250 Hz, 400 Hz, 500 Hz, 630 Hz
- Selectable Q: 0.7, 1.4, 2.9, 5.0, 11.5
- High Mid:
- Selectable Gain: ±2 dB, ±4 dB, ±6 dB @1 kHz, 1.6 kHz, 2.5 kHz, 4 kHz, 6.3 kHz
- Selectable Q: 0.7, 1.4, 2.9, 5.0, 11.5
- High Shelf:
- Selectable Gain: ±2 dB, ±4 dB, ±6 dB @10 kHz
- Volume Limiter:
- Selectable: 0 dB to -48 dB in 3 dB steps
- Volume Lock:
- Selectable: 0 dB to -70 dB
- Battery Life: 4–6 hours (continuous use) with AA batteries
- Net Weight: 158 g, without batteries
- Dimensions: 99 mm x 66 mm x 23 mm (3.9 in. x 2.6 in. x 0.9 in.) H x W x D
The Shure P10R+-H22 Diversity Bodypack Receiver is perfect for performers using the PSM 1000 Wireless Personal Monitor System. It has a sleek design and weighs only 158 g without batteries, with dimensions of 99 mm x 66 mm x 23 mm (3.9 in. x 2.6 in. x 0.9 in.) H x W x D. This receiver offers features like full bandwidth RF scan and Automatic RF Gain Control for great signal stability. CueMode allows you to easily monitor different stage mixes and store up to 20 channels for quick reference. Optional advanced rechargeability means you don't need disposable batteries and it has extended usage times.
